High-Range Motorized Triple Zoom Lens
HR-2500(E) / HR-5000(E)
20x up to 2500x / 5000x Magnification
Triple objective turret
Optimum lighting
Available in both Motorized and Manual versions
The dual illumination mechanism provides both co-axial and ring lighting.
The operator is free to choose either setting or a mix of both in order to cover a multitude of applications.
The lighting system is integrated into the lens and no additional cables are required.
| Range | Wide-Range | Mid-Range | High-Range HR-2500E | Super High-Range HR-5000E |
|---|---|---|---|---|
| Magnification | 20x-140x | 140x-1000x | 350x-2500x | 700x-5000x |
| Working Distance | 18 mm | 10 mm | 10 mm | 3.4 mm |
| Horizontal View | 15.4 - 2.21 mm | 2.18 - 0.31 mm | 0.87 - 0.12 mm | 0.43 - 0.06 mm |
| Depth-of-Field | 0.72 - 0.072 mm | 0.09 - 0.007 mm | 0.04 - 0.002 mm | 0.01 - 0.0007 mm |
| Lighting Method | ||||
| ACS Function | Yes | Yes | Yes | Yes |
| Motorization | ||||
Adapters
Directional Lighting Adapter
Included with the lens
Fixed Iris Adapter
Variable Iris Adapter
Center Iris Adapter
Co-Axial Polarizing Adapter
Single Wavelength Adapter
Ring Light (Dark Field)
Polarizing Adapter
Polarizing Adapter
Diffusing Adapter for Wide-Range & High-Range Objective Lenses
Side Lighting Adapter for Mid-Range Objective Lens
External Side Lighting Adapter
Optical Rotary Adapter
Adapters Effects on Samples
